Suspension Components for 1987 Chevrolet V10
No.
Part # / Description / Price
Price
1
Ball Joint
GM
GM Positions: Left
Notes: PARTS: Part included with upper control arm.
Description: 10-20, gas. Pick-up. 10-20 series. 2wd, 1/2 ton. G10-20, G1500-2500 vans. Blazer, Jimmy, Suburban. 10-20 series. Vacuum Brakes. 2wd, upper.
2
Ball Joint GM
GM Positions: Left
Notes: PARTS: Part included with lower control arm.
Description: Pick-up. 10-20 series. 2wd, 1/2 ton. G10-20, G1500-2500 vans. Blazer, Jimmy, Suburban. 10-20 series. 4wd. 2wd, lower.
3
Upper Control Arm GM
GM Positions: Left
Description: 10-20, gas. G10-20, G1500-2500 vans. Left side. 2wd.
3
Upper Control Arm GM
GM Positions: Right
Description: 10-20, gas. G10-20, G1500-2500 vans. Right side. 2wd.
Suspension component that connects and provides pivotal movement of the Steering Knuckle to he vehicle.
Suspension component that connects and provides pivotal movement of the Steering Knuckle to he vehicle.
MSRP $313.41
$221.51
MSRP $313.41
$221.51
4
Upper Control Arm Shaft GM
GM Description: 10-20. All models. 1500-2500 series. Shaft. G10-20, G1500-2500 vans. 2wd.
5
Upper Shaft Bushing GM
GM Description: Bushings. All. 10-20 series. All models. 1500-2500 series. G10-20, G1500-2500 vans. 2wd.
7
Lower Control Arm GM
GM Positions: Right
Description: Pick-up. 10 series. Right side. Blazer, Jimmy, Suburban. 10 series. 2wd.
9
Lower Control Arm Shaft GM
GM Positions: Right
Description: 30, hd. 2wd, hd suspension. Shaft. All. 30 series. With heavy duty. Left side. G30. All models. 3500 series.
9
Lower Control Arm Shaft GM
GM Positions: Left
Description: 30, hd. 2wd, hd suspension. Shaft. All. 30 series. With heavy duty. Right side. G30. All models. 3500 series.
10
Lower Control Arm Bushing GM
GM Description: 10-20. All models. 1500-2500 series. G10-20, G1500-2500 vans. 2wd.
Suspension Control Arm Bushing.
Suspension Control Arm Bushing.
MSRP $6.14
$4.52
MSRP $6.14
$4.52
11
Coil Spring GM
GM Description: 2wd without 15,000 gvwr, 3/4 ton. 2wd without 15,000 gvwr, 1 ton. Express, savana. Right. 1/2 ton. Suspension code:6wt,6ww,7wt,7ww,jwt,jww. 1/2 ton, light duty. Left. 1/2 ton. Spring Code-6WW,7WW. 1/2, 3/4 & 1 ton, 1996 new style, 3/4 ton, hd.
13
Suspension Stabilizer Bar Bushing GM
GM Description: To frame. 2wd, 26.92mm. 2wd, standard. S-series. Pick-up. Without sport chassis pkg. 2WD. with Sport package.
14
Suspension Shock Absorber 2 GM
GM Positions: Left
Description: 2wd, 1/2 & 3/4. 2wd, 1/2 ton. Exc.I-Beam Suspension. Exc.Motor Home. 3,050 Lbs. Front Axle. 2wd, standard.
2 This part contains hazardous materials. Extra shipping costs apply.
No.
Part # / Description / Price
Price
3
Tie Rod End GM
GM Positions: Right
Description: 4wd. All. 10-20 series. Right. All models. 1500-2500 series.
4
Tie Rod End GM
GM Positions: Left
Description: 4wd. All. 10-20 series. Left. All models. 1500-2500 series.
5
MSRP $99.04
$54.18
5
Acdelcoâ„¢ Steering Drag Link GM
GM Description: Pitman Arm TO Steering Knuckle. Long. 4wd, front. All models.
6
Acdelcoâ„¢ Steering Drag Link GM
GM Description: Pitman Arm TO Steering Knuckle. Short. 4wd, rear. All models.
6
MSRP $83.21
$52.42
7
Acdelcoâ„¢ Steering Tie Rod End Adjusting Sleeve GM
GM Description: 4wd. Pitman Arm TO Steering Knuckle. All models.
8
Suspension Shock Absorber 2 GM
GM Description: All. Standard. 4wd, hd. Color-Silver. Vendor:acdelco. Vendor #530-202. 4wd, with 4 shocks, outer. JTEC Engine Control Module.
2 This part contains hazardous materials. Extra shipping costs apply.
